Product Description

09CuPCrNi-A weathering plate is a kind of atmospheric corrosion resistant steel, belonging to ordinary low alloy steel, mainly used for engineering structures, such as railways, vehicles, bridges, towers and other steel structures exposed to the atmosphere for a long time. The steel plate is made of ordinary carbon steel with a small amount of corrosion-resistant elements such as copper and nickel. It has the characteristics of high-quality steel such as toughness, ductility, formability, welding and cutting, wear resistance, high temperature resistance and fatigue resistance. The weather resistance is 2 to 8 times that of ordinary carbon steel, and the coating performance is 1.5 to 10 times that of ordinary carbon steel.
09CuPCrNi-A steel plate meet China Standard: GB4171-84; With Thickness: 6mm-300mm, Width: 1500mm-4050mm, Length: 3000mm-15000mm. And with Yield Strength (MPa) min.    is 295. Tensile Strength (MPa) min. is 431. Elongation min. % is 24;

During the production process, 09CuPCrNi-A weathering plate also needs to be rust-proofed. Usually, the rust-free process method is adopted to complete the rust treatment process within 3 hours at an outdoor temperature of 25 degrees Celsius. This process method can form a dense oxide layer protective film on the surface of the steel plate to prevent further rusting of the steel plate, and at the same time, it can also improve the weather resistance and service life of the steel plate.
